How to adjust an electromagnetic flowmeter?

The electromagnetic flowmeter itself has this function, which can be manually debugged to adjust the flow rate and caliber size. The specific operation process is as follows: First, enter the password of the electromagnetic flowmeter to enter the menu and find the caliber column. For example, if the caliber is DN50 and you want to increase the flow rate, change the caliber from DN50 to DN65, and its flow rate will naturally be larger than that of DN50.. Secondly, there is another method to adjust the traffic volume. Similarly, enter the password to enter the menu and find the K coefficient column. For example, if the K coefficient is 1.065, if you want to increase the traffic volume by a large K coefficient value, the larger the value, the greater the K coefficient, and at this time, the traffic volume will be larger. The above is how to adjust the flow rate of an electromagnetic flowmeter. Do not move the flow rate unless it is operated by personnel. If the parameters inside are changed, the electromagnetic flowmeter will not accurately measure the flow rate. How to debug an electromagnetic flowmeter? After purchasing an electromagnetic flowmeter, if you want to debug it, the editor will summarize as follows: Before debugging, the electromagnetic flowmeter should be thoroughly inspected using pipelines and flow collapse gauges, including cleaning of pipeline debris. Oil medium pipelines do not need to be dried. The inspection before debugging also includes the inspection of electrical circuits. Firstly, the connection of the circuit should be checked to ensure reliable grounding before conducting other circuit tests and inspections to avoid capacitive effects

How to adjust the flow rate of electromagnetic flowmeter

on the circuit, stored electricity, or damage to the instrument caused by measuring power supply. In addition, insulation resistance and grounding resistance tests are also required. Water commissioning: Whether it is an instrument for measuring aqueous suspension or oily media, the electromagnetic flowmeter should simulate the actual temperature, pressure, flow rate and other conditions of the measured medium for water commissioning before formal commissioning. If any abnormalities or missing parameters occur during the water test, the instrument should be tested individually or sent to the production unit for calibration. System investigation test: After completing the single function water test and the preparatory debugging of the control host, the electromagnetic flowmeter can proceed with system debugging. Oil medium pipelines need to be dried before the tested medium can be introduced for system operation. During system debugging, the host should pre code and scan each measurement point to ensure that all instrument components are in normal working condition before proceeding with functional debugging. During functional debugging, the host system reads parameters and performs critical value alarm tests on each instrument, then writes control data, performs debugging one by one, and sends relevant data to the relevant upper computer for analysis. How to set the parameters of an electromagnetic flowmeter? Usually, the parameters of an electromagnetic flowmeter need to be set, but many people are not sure how to set its parameters. Now let me briefly explain how to set the parameters of an electromagnetic flowmeter. The general parameters are set within a certain range, and there are certain differences among differen

How to adjust the flow rate of electromagnetic flowmeter | sx electromagnetic flowmeter zero adjustment in the simplest three steps

How to adjust an electromagnetic flowmeter?
