1. What does the arrow marking of ABB electromagnetic flowmeter R and F mean?

F -- FORWARD, the arrow represents forward flow, that is, the factory set positive direction R -- REVERSE, and the arrow represents reverse flow.

2. Instructions for using differential pressure gas flowmeter.

The core reading logic of differential pressure gas flowmeter is to calculate real-time gas flow by measuring the upstream and downstream pressure difference combined with instrument parameters. To understand it, it is necessary to first clarify the key parts of the display panel, parameter meaning, and calibration premise. The conventional display panel of a differential pressure gas flowmeter will contain three types of core data: • Real time differential pressure value: generally labeled as Δ P, mostly in Pa or kPa, representing the gas pressure difference upstream and downstream of the flowmeter • Operating parameters: including the real-time operating pressure and temperature of the current gas, and some instruments will also display the pressure and temperature under standard conditions (i.e. atmospheric pressure and 20 ℃ environment under standard conditions) • Flow data: divided into instantaneous flow rate and cumulative flow rate, with instantaneous flow rate units mostly in m ³/h and Nm ³/h (standard flow rate), and cumulative flow rate being the total volume of gas passed, mostly in m ³ and Nm ³ Key parameter interpretation and reading rules • Confirmation of display unit: Some instruments support switching units, and it is necessary to first confirm whether the current displayed flow rate is the operating condition flow rate or the standard condition flow rate. The conversion between the two needs

to be combined with the current temperature and pressure parameters. Standard condition flow rate=operating condition flow rate x (actual pressure/standard atmospheric pressure) x (standard temperature/actual temperature). The standard atmospheric pressure is taken as rolling signal 101.325kPa, and the standard temperature is taken as 20 ℃ or 0 ℃, with slight differences in industry standards • Matching instrument coefficient: Each flowmeter will be marked with a flow coefficient K or a range when it leaves the factory, such as a range of 0-1000Nm ³/h and a differential pressure range of 0-10kPa, When reading, it is necessary to match the flow value corresponding to the actual differential pressure with the range Tanki meter. Some intelligent instruments will automatically complete the conversion. Note that temperature and pressure compensation: flow meters with temperature and pressure compensation will automatically correct the flow calculation result based on real-time temperature and pressure. Instruments without compensation can only display the instantaneous flow under operating conditions and need to be manually converted to standard flow Key points for troubleshooting abnormal readings - Differential pressure value of 0: High probability of upstream and downstream pressure taps being blocked, pressure pipes leaking, or instrument power supply being abnormal - Flow reading far above rated range: Check if the pressure tap is reversed or if the parameter settings are incorrect - Excessive reading fluctuations: Check if the gas source has liquid, if there is liquid accumulation in the pressure pipe, or if there is pulsating airflow in the pipeline Precautions for Calibration and Data Validation - Regularly use stand
