1. What are the advantages of vortex flowmeter?
Functions
1. The body also integrates temperature and pressure compensation function, which can measure the standard volume flow rate or standard mass flow rate of the fluid.
2、 Fully intelligent and digital circuit design, capable of automatically compensating for measured fluid density or standard condition volume calculation.
3、 The new digital filtering and correction functions make flow measurement more accurate and reliable.
4、 The battery powered type can work continuously for more than two years without the need for an external power source.
5、 The brand new dot matrix Chinese character LCD display is more convenient to use and operate. /iknow-pic.cdn.bcebos.com/cf1b9d16fdfaaf5171634bd2835494eef11f7adf"target="_blank"title=" Click to view large image "class=" ikqc_img.link ">/i know pic.cdn. bcebos. com/cf1b9d16fdfaaf5171634bd2835494eef11f7adf? X-bce-process=image% 2Freesize% 2Cmlfit% 2Cw_600% 2Cw_800% 2Climat1% 2Fquality% 2Cq_85% 2FFormat% 2Cf_auto" esrc=“ https://iknow-pic.cdn.bcebos.com/cf1b9d16fdfaaf5171634bd2835494eef11f7adf Additional information: In the manual for common faults of vortex flow meters, the flow range indicated is the flow range used for a specific reference medium, such as liquid, which generally refers to normal water. When used for other media, the available flow range will vary depending on the viscosity and density of the medium. As the oil flow standard device uses diesel with a viscosity greater than water and a density smaller than water as the calibration medium, the lower limit flow rate of the flowmeter will generally be correspondingly increased, narrowing the available flow range. Therefo
1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;
2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15
1.2-6; DN20
1.5---10； DN25：2---16； DN32
1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh.com
3. Can vortex flowmeters be installed vertically?
Vortex flowmeters can be installed vertically, but some installation points need to be noted. Firstly, vortex flowmeters are feasible for vertical installa
